Jupiter 105

Classy Wideline System with 105mm x 25 mm section.

VEDIC Jupiter 105 series provides a Wide line design system providing full height partition as well as block design adaptability giving a moderate acoustic performance.

Compatible to glass thickness:

• 10mm & 12mm Clear toughened or 10.76,11.10 & 11.52 Clear laminated glass.
• Single Glazed Partition ( Block Design Compatible in Divider system or Stick
• On system
• Partition height can be considered upto 3000 mm.
• All exposed aluminum sections are Anodized and come in 6063 with T5 Grade.

Shades available: Silver Anodized / Mid Night Black /(Mill finish also available, Anodizing shades or powder coating subject to test on VEDIC profiles min qty 500 sq ft)

Door frames: Doors can be mounted either on Hinges, patch systems or Pivot doors for frameless glass doors,Stile doors also can be incorporated in 65 series and 75 series both..

Sound insulation capacity: 32 dB to 34 dB
